Accurate Obstacle Avoidance without Delay, Multiple Protections
0.4cm Detecting Precision, Transeiver with 60° Beam Angle and 0 Fade Area
SU04
PIXHAWK Ultrasonic Sensor
First Module with Technology of Dual Filters, 30ms Extreme Fast Response
Receiving Ultrasonic Echo Signals
30ms
Technology of Hardware and Software Dual Filters, 30ms Extreme Fast Response
With the integrated 32-bit processor and a breakthrough of hardware and software dual filters technology adopted, SU04 ensures the accuracy and realizes the 30ms fast response, solving the common delay problem of other products. This function is helpful for flight operation such as agricultural drones, detecting the height real-time and feedback in time when there’s obstacle and protect both operator and drone.
SU04 is compatible with RadioLink flight controller PIXHAWK, MINPIX and TURBO PIX with the I2C and UART(MAVlink protocol) automatically identified.
Ultrasonic Transmitting
High Precision of 0.4cm
With 0.4cm detecting accuracy and zero fade area, SU04 can quickly spot barrier .
60° beam angle
60° Beam Angle, Overall Synchronous Avoidance
60° beam angle ensures environment detection and obstacle sense in real-time. Connect SU04 with flight controller PIXHAWK (of RadioLink or open source) /MINI PIX/TURBO PIX to realize obstacle avoidance of maximum 2 directions*
to guarantee safer flight.
Safety Guaranteed for Outdoors Operation and Training
Agriculture: SU04 enables drones to altitude hold downward to steep slopes or horizontal obstacle avoidance. Farmers are able to fertilize every inch of the land easily.
Rescue: With SU04 equipped, the drone can detect and fly along barriers. Drone operators are worried free from misjudgment, blind spots or effects from wind and airflow and have more effective and safer rescue.
Training: With the SU04, drone beginners can always avoid the collision to the floor or ceiling while pushing the throttle. Protection for players and teaching devices makes training reassuring.
Flight Controller
I2C Transfer Board
GPS
Obstacle Avoidance
Altittude Holding
MINIPIX Connection
LED
Module
Transceiver with Single Detector
SU04 is a ultrasonic transceiver with super mini size of 20*22*19MM （0.79”*0.87”*0.75”） and light weight of 8g(0.28oz), even 210 racing drone can easily carry.
